Golf Cart Tire Size Chart: Dimensions, Wheels and Fit (2026)

As an Amazon Associate, we earn from qualifying purchases. This helps support our site at no extra cost to you.

Choose golf cart tires from the exact vehicle and wheel specifications, then choose tread for the surfaces you use. A tire-size chart explains dimensions; clearance, road eligibility and safe fitment need their own checks. A matching wheel bolt pattern is only one part of compatibility.

If you are shopping because a tire went flat, first use our repair-or-replace guide to check the repair limits and whether a complete spare wheel fits.

Read the size before comparing wheels

In 18x8.50-8, the nominal dimensions are 18 inches overall diameter, 8.50 inches width and an 8-inch rim. In 205/50R10, the width is 205 mm, the sidewall height is 50% of that width, the rim diameter is 10 inches and R denotes radial construction.

For metric sizes, calculated diameter in inches is:

Rim diameter + 2 × width in mm × aspect ratio ÷ 25.4.

Use the aspect ratio as a fraction: 50% is 0.50. Here is one consolidated chart; these are nominal dimensions, not approved fitments.

Size	Nominal diameter	Nominal width	Rim diameter
18x8.50-8	18.0 in	8.50 in	8 in
205/50-10	18.1 in	8.07 in	10 in
205/55-10	18.9 in	8.07 in	10 in
205/65-10	20.5 in	8.07 in	10 in
215/60-8	18.2 in	8.46 in	8 in
215/40-12	18.8 in	8.46 in	12 in
215/35-14	19.9 in	8.46 in	14 in
20x10-10	20.0 in	10.00 in	10 in
22x11-10	22.0 in	11.00 in	10 in
23x10-14	23.0 in	10.00 in	14 in

Why the calculation is not a clearance measurement

Kenda's current K3005R Kruizer specifications list its 205/50R10 part 122373 at 462 mm overall diameter, or 18.19 inches. The nominal formula gives 18.07 inches. Its published section width is 196 mm rather than the nominal 205 mm.

That roughly 0.12-inch diameter difference is small, but it shows why a nominal chart cannot resolve a tight clearance. Compare the exact manufacturer's dimensions on its specified measuring rim, and have clearance checked through steering and suspension movement with the intended load. Do not use a brand-wide maximum tire height as an approval.

Wheel fit: more than four holes

Before buying a tire/wheel package, obtain an application confirmation for your model, year, axle and suspension. Check:

• Bolt pattern, stud diameter/thread and lug-seat shape.
• Wheel diameter, width, offset and center-bore/hub fit.
• Tire size, approved rim-width range, load and speed capability.
• Brake, steering, body and suspension clearance throughout movement.
• Vehicle load limits and any required lift or associated parts.

Do not force a wheel onto the hub, substitute a near-matching lug thread or assume spacers solve a clearance problem. A pre-mounted tire may fit its supplied rim while the complete assembly remains unsuitable for the cart.

Club Car's approved tire matrix demonstrates the level of detail to seek: assembly part numbers, specific vehicle prefixes, wheel offset, lug part, pressure and torque. Its Precedent table lists LOADSTAR 205/55-10 packages at 18 PSI and KRAKEN 22x10-10 packages at 20 PSI, with designated applications requiring lift kit AM15009001. The matrix approves those specific packages, not every Precedent or aftermarket wheel of those sizes, so have a dealer match the actual vehicle and assembly identifiers.

Tread and construction: compare exact tires

For course use, start with the course's permitted tread requirements. For pavement, compare tires explicitly specified for that application. For gravel or trails, check both the vehicle's permitted use and the tire maker's application; aggressive tread does not make a cart suitable for rough terrain.

Kenda identifies the K3005R as a radial for golf carts and low-speed vehicles. Ride quality on your cart also comes down to pressure, alignment, tire dimensions, load and suspension.

Ply rating is also insufficient to choose a load capacity. The same Kenda table lists 4PR for both 205/50R10 part 122373, rated 307 kg, and 205/65R10 part 122380, rated 412 kg under their specified conditions. Those are about 677 and 908 lb respectively; there is no universal 815-lb rating for a “4-ply” golf cart tire. A tire's maximum rating does not increase the cart's payload limit, and four maximum tire ratings are not a substitute for axle-load approval.

The European Kenda listing shows E-mark information. Confirm the exact US-market tire's applicable certification and markings with its manufacturer rather than relying on a European product page or generic “DOT approved” seller wording. Tires alone do not make a cart eligible for registration or a route.

What owners actually reported about radials

In a December 2018 Talk of The Villages discussion, Pmount reported owning a 2014 cart with bias-ply tires and a 2017 Yamaha with radials. They preferred the radial ride, but reported front tires wearing out at 4,500 miles while the newer cart's alignment was wrong, followed by an alignment repair and replacement tires. They also reported 11,000 miles on the older cart's bias-ply tires.

In the same thread on December 12, JoelJohnson described intermittent bouncing on radials fitted to a 2016 Club Car bought in 2017; raising pressure had not solved it. They support checking the whole installation rather than expecting a set radial ride or wear advantage.

Larger tires: the geometry

At the same wheel rpm, a nominal 22-inch tire travels 22 ÷ 18 = 1.222, or 22.2% farther per revolution than an 18-inch tire. At the same axle torque, the ideal force at the ground becomes 18 ÷ 22 = 0.818, or about 18.2% lower. The tire radius increases by 2 inches.

These calculations assume the stated diameters and unchanged wheel rpm/torque; motor load, controller limits, tire mass, tread and losses can change the actual result. A lift, larger tires or a faster reading does not increase the vehicle's rated load or approved operating speed.

Pressure, condition and installation

Use the vehicle label or exact approved package specification for cold pressure. The sidewall maximum is not automatically the vehicle operating pressure. NHTSA's TireWise guidance recommends monthly pressure checks and explains that vehicle pressure specifications take precedence over the sidewall marking. Do not lower pressure for comfort or sand use without maker approval.

Check for damage, unusual wear, persistent air loss, vibration and changed handling. Stop using a damaged tire and seek a tire professional's assessment; replacing tires without finding an alignment or suspension fault can repeat the wear.

For tires carrying a DOT Tire Identification Number, the last four digits show manufacturing week and year: 2423 means week 24 of 2023. NHTSA notes that some manufacturers specify replacement at six to ten years. Follow the exact tire and vehicle maker's age guidance and inspection requirements, including stored tires. Use our tire-age and date-code worksheet to record all four tires and handle unreadable markings.

Wheel work needs the cart's specified jack/support points, stable ground, chocks and rated supports. Never work beneath a cart held only by a jack. Correct lug torque and an appropriate torque tool are necessary; follow the exact wheel/cart instructions for seating, tightening and rechecking. Have a tire shop mount tires on rims when you lack the specified equipment and experience.

Before reinstalling a wheel, use our lug-nut torque source checklist to match the assembly, hardware and wrench units.

Request an itemized quote for tires, rims, compatible lugs, mounting/balancing, any approved suspension changes and installation. Compare the total fitted package with tires on serviceable existing wheels, rather than assuming a combo is cheaper.

See the tire-pressure guide, lift-kit guide and jack-point guide for the related checks, or find a dealer to confirm the exact assembly.
